PAT-Cell-Gas
For In-Situ Gas Analysis Developed for in-situ gas analysis of battery materials in a flow-through set-up, the PAT-Cell-Gas features a gas inlet and outlet with self-locking couplings that are compatible with 1/16 in. Swagelok tube fittings. Optional built-in pressure sensor or valve port for gas sampling with a syringe are also available. The PAT-Cell-Gas combines […]
PAT-Cell-HT
Heat-resistant PAT-Cell for up to 200 deg C. For 2- & 3-electrode testing at elevated temperatures The PAT-Cell-HT is a test cell for 2- and 3-electrode measurements on battery materials at temperatures up to 200°C. It uses the modular PAT-Core concept and can therefore be used for a variety of test purposes. The cell has no wiring […]
PAT-Cell-Twin-Ref
The PAT-Cell-TwinRef is a special version of the PAT-Cell which accommodates the use of a second reference electrode. This enables simultaneous measurements using two reference electrodes, for instance with LFP and LTO. Since both ring electrodes are arranged face-to-face, their SOC can be easily adjusted.
PAT-Cell
The ideal test cell for high-throughput battery testing. The PAT-Cell is a test cell for 2- and 3-electrode measurements on battery materials. It uses the modular PAT-Core concept and can therefore be used for a variety of test purposes. The cell has no wiring but is inserted directly into a PAT battery tester or connected to any commercially available […]
PAT-Cell-Press
For testing under pressure The PAT-Cell-Press is a pressure test cell for measuring gas evolution and drawing gas samples (option). Its advanced design includes a laser welded pressure sensor and glass-to-metal seals. The number of non-permanent seals is reduced to its minimum: a single seal between cell lid and base and a ferrule when the […]
